KRCCS/KRCCH Reverse Cam
The thrust cam unit KRCCS and KRCVS series is the optimum cam unit for upper bending of panel. 8 models in total, regular type and highly rigid type and 4 sizes in width, are available.
Details
1.Rigid structure integrated into the casting is used. The highly rigid type is reinforcing the backup wall of cam slider B. It is not necessary to machine the die for backup.
2.Cam slider B has a V guide design. The design is resistant to reaction force at the side. (145 or more in width)
3.Urethane stopper for shock absorption are provided on the stopper plate to prevent direct force on the screws.
4.In cam slider B, the thrust block is used as the stopper. lt is designed to prevent lift exceeding the specified travel Push bolt tapped holes for locking the bottom dead center are drilled.
